Omnio LED OM1 - LS411LED

A compact and versatile surface mount luminare suitable for wall mount and ground mount

Product Overview

A compact, adjustable luminaire with an aesthetically pleasing form, featuring integral line voltage driver and a wide range of adjustability, which makes it ideal for general landscape lighting applications. The epoxy-coated, marine grade aluminium construction ensures a long service life, even in harsh environments.

Features

Lumen Output 970 lm Power Consumption 14.2 W Typical Lifetime (TM21 Reported) > 60,000 hours @ 50°C Ambient (B10, L90, TM21 Reported) Typical Lifetime (TM21 Projected) 179,506 hours @ 50°C Ambient (B10, L90, TM21 Projected) Control Protocol PWM (0-10V, DMX, DALI) IP Rating IP67 Compliance ETL - USA & Canada CE Color Options Warm White Cool White RGB Blue (470 nm)

Specifications

Accessories


LS6023 Pole Clamp

Product Configurator

Customise Omnio LED OM1 below

Light Engine

Required

9W (09)

12W (12)

15W (15)

Light Source

Required

Static White (D7)

Static White (D7)

2,700 K (80 CRI, 3 SDCM)

Static White (H6)

Static White (H6)

3,000 K (80 CRI, 3 SDCM)

Static White (W4)

Static White (W4)

4,000 K (80 CRI, 3 SDCM)

Single Color (B4)

Single Color (B4)

Blue (470 nm)

Dynamic Color (M4)

Dynamic Color (M4)

RGB

Beam Angles

Published angles may vary slightly to photometric data. Please refer to IES files where relevant.

Required

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Linear (LN)

Linear (LN)

20° x 40°

Shielding

Required

Flush (1)

Snoot (2)

Mounting

Required

Surface Mount (A)

Pole clamp (B)

Concrete Anchor (C)

Input Voltage

Required

110-240 Vac, 50/60 Hz (01)

110-240 Vac, 50/60 Hz (01)

Mains Voltage

24 Vdc (07)

24 Vdc (07)

Non-Dimmable

24 Vdc Dimmable (27)

24 Vdc Dimmable (27)

PWM Dimmable Driver

Finish

Required

Black (BL)

Black (BL)

Black powder coat

Anodic Silver (SL)

Anodic Silver (SL)

Anodic silver powder coat

White (WT)

White (WT)

White powder coat

Custom RAL (CC)

Custom RAL (CC)

A one-off custom colour setup fee applies. Click on 'More Info' button to add to your enquiry. Contact Lumascape for volume discount on set-up fee.
